This reference amplifier features an ultra-wideband (400kHz) circuitry with low THD and IMD.
Our proprietary zero total feedback audio circuitry delivers a sound unlike any other car audio brand.
The result of years of work, it recreates the soundstage with all the realism and speed present in the original recording.
- Class A FETs input preamplifier.
- Class A amplifier stage with dual current mirror differential with FETs and TRANSISTORS, ultra-wide bandwidth, and low local feedback.
- Class AB MOSFET power stage with low local current feedback allows speaker output currents of >40A in less than 1 uS.
- No output current limiter.
- Regulated 1400W 12V power supply.
- Hand-assembled in our laboratory by our skilled Craftsmen.


  Technical specifications

- 2x 250W continuous rms (4 ohm), (0.2% THD and 0.1% IMD from 20hz to 20khz) at 12V battery

- 2x 500 W continous rms (2 ohm), (0.25% THD and 0.1% IMD from 20hz to 20khz) at 12V battery

- 1000W rms mono (0.25% THD and 0.1% IMD from 20hz to 20khz) a 12V battery

- frequency response [-3Db]: 8 hz and > 400 Khz (nominal power 4 ohm)

- imput impedance: 10 Kohm (max 500 mVrms, minimum 6 Vrms)

- S/N ratio: > 120 Db weight "A"

- 12V deain current: from 3.5A (idle) to 160A (mono)

- dimensions:  480 x 295 x 66 mm

- weight: 11.5Kg
